Product code: SRVS2KIL
SRVS2KIL | SE Easy UPS Online SRVS 2000VA 230V
Call for Price
Schneider Electric SRVS2KIL
[dt_divider style="thin" /]Schneider Electric Easy UPS 1 Ph On-Line, 2000VA, Tower, 230V, 4x IEC C13 outlets, Intelligent Card Slot, LCD, Extended runtime
Download Product DatasheetDescription
Characteristics
1 Reviews
Description
Schneider Electric SRVS2KIL 2000VA/1600W double-conversion on-line pure sine wave Tower Easy UPS High quality, designed for essential power protection for unstable power conditions, ensuring consistent and reliable connectivity at the most critical moments. This 2000VA double-conversion on-line tower UPS provides pure sine wave power and extended runtime to handle a wide voltage range and inconsistent power conditions.
[dt_divider style=”thin” /]
Overview
| Main | |
| Main input voltage | 230 V |
| Other input voltage | 220 V 240 V |
| Main output voltage | 230 V |
| Other output voltage | 220 V 240 V |
| Rated power in W | 1600 W |
| Rated power in VA | 2000 VA |
| Input Connection type | IEC 60320 C14 |
| nb of power socket outlets | 4 IEC 60320 C13 |
| Cable length | 1.52 m |
| Number of cables | 1 |
| Provided equipment | Basic UPS signalling RS-232 cable CD with software 1 x DC cable User manual USB cable |
| General | |
| Number of power module filled slots | 0 |
| Number of power module free slots | 0 |
| Redundant | No |
| Physical | |
| Color | Black |
| Height | 33.6 cm |
| Width | 33.5 cm |
| Depth | 42.5 cm |
| Net weight | 45.4 kg |
| Mounting location | Front |
| Mounting preference | No preference |
| Mounting mode | Not rack-mountable |
| USB compatible | Yes |
| Mounting position | Vertical |
| Input | |
| Input voltage limits | 110…285 V half load 160…280 V full load |
| Network frequency | 40…70 Hz auto sensing |
| Output | |
| Maximum Configurable Power in VA | 2000 VC |
| Maximum configurable power in W | 1600 W |
| Output frequency | 50/60 Hz +/- 3 Hz sync to mains |
| UPS type | Double conversion online |
| Wave type | Sine wave |
| Efficiency | 88 % (full load) |
| Additional information | Configurable for 220 : 230 or 240 nominal output voltage |
| Bypass type | Internal bypass (automatic and manual) |
| Crest factor | 3 : 1 |
| Conformance | |
| product certifications | CE |
| Standards | EN/IEC 62040-1 EN/IEC 62040-2 |
| Environmental | |
| Ambient air temperature for operation | 0…40 °C |
| Relative humidity | 0…95 % non-condensing |
| Operating altitude | 0…3000 m |
| Ambient air temperature for storage | -20…50 °C |
| Storage Relative Humidity | non-condensing 0…95 % |
| Storage altitude | 0…15000 m |
| Acoustic level | 50 dBA |
| IP degree of protection | IP20 |
| Batteries & Runtime | |
| Efficiency | View Efficiency Graph |
| Battery type | Lead-acid battery |
| Battery voltage | 72 V |
| Number of batteries filled slots | 0 |
| Number of battery free slots | 0 |
| Battery recharge time | 4 h |
| Battery life | 3…5 year(s) |
| Battery charger power | 242 W rated |
| Communications & Management | |
| Alarm | Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm |
| Control panel | Multifunction LCD status and control console |
| Free slots | 1 |
| Surge Protection and Filtering | |
| Surge energy rate | 600 J |
| Packing Units | |
| Package 1 Weight | 49.3 kg |
| Package 1 Height | 46.5 cm |
| Package 1 width | 56 cm |
| Package 1 Length | 56.5 cm |
| Contractual warranty | |
| Warranty | 2 years repair or replace |
