BGM2200-GR | APC Back-UPS Pro for Gaming, 2200VA/1320W

Subscribe to news letter

Main
Main Input Voltage	230 V AC 1 phase
Input Voltage	230 V
Input Connection Type	Schuko
Maximum input current	12 A
Input harmonic distortion	Less than 3 % for full load
Input protection type	Circuit breaker
Switching current capacity	15 A
Plug standard	Schuko
Input voltage limits	168…302 V
Network frequency	50/60 Hz +/- 3 Hz
Output voltage	230 V AC 1 phase
Rated power in W	1320 W
rated power in VA	2200 VA
Output connection type	4 Schuko surge 2 IEC 60320 C13 USB Charging Port USB type A + C
Maximum configurable power in VA	2200 VA
Maximum configurable power in W	1320 W
Transfer time	8 ms typical : 10 ms maximum
UPS type	Line interactive
Wave type	Sine wave
Full load runtime	00:30:00
Half load runtime	00:04:19
Output frequency	50/60 Hz +/- 3 Hz sync to mains

Complementary
Battery type	Lead-acid internal included
Control panel	Multifunction LCD status and control console
Free slots	0
Alarm	Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
UPS connectivity	USB port
Surge energy rate	1080 J
Noise suppression	Full time multi-pole noise filtering : 5% of IEEE surge let-through : zero clamping response time: instantaneous
Cable length	1.5 m
Number of cables	1
Colour	White
Height	292.1 mm
Width	104.14 mm
Depth	408.94 mm
Net weight	12.3 kg
Mounting support	Floor
Mounting preference	No preference
Mounting mode	Not rack-mountable
Two post mountable	0
USB compatible	Yes
Mounting position	Vertical
Mounting mode	Tower
Number of power module free slots	0
Number preinstalled power module	0
Additional specification	Gaming performance
Redundant	No
Range of product	Back-UPS Pro
Product or component type	Uninterruptible power supply (UPS)

Environmental
Product certifications	CE CB
Equipment protection policy	Lifetime : 50000 euros
Ambient air temperature for operation	0…40 °C
Ambient air temperature for storage	Ambient air temperature for storage
Storage altitude	0…3048 m
IP degree of protection	IP20
Relative humidity	0…95 %
Storage Relative Humidity	0…95 %
Acoustic level	45 dBA
Operating altitude	0…10000 ft

Batteries & Runtime
Run Time	View Run Time Graph
Efficiency	View Efficiency Graph
Battery type	Lead-acid battery
Battery voltage	24 V
Number of battery filled slots	1
Number of battery free slots	0
Battery recharge time	16 h
Number of battery replacement quantity	1
Overcurrent protection	15 A
Battery life	3…5 year(s)
Battery charger power	12 W rated

Contractual warranty
Warranty (in months)	24

APC BGM2200-GR
